Over the past few decades, steel has emerged as one of the most reliable and useful materials for industries across the spectrum. It is used in different fields such as construction, manufacturing, and mining, and there is a huge demand for steel from all these industries to serve different mechanical purposes. Steel is used as a raw material to manufacture different products but there is one steel product that is used in different industries to execute different operations, which is a steel pipe. A much-relied and effective steel product, it is available in different forms and there are numerous variants of Carbon Steel Pipe ASTM A 106 Gr C Pipes that have made industrial operations smoother and more efficient.
Carbon Steel Pipe ASTM A 106 Gr C Pipes is one such variant that serves different piping requirements in different industries and has proven its worth through its substantial quality and ability to be used in multiple applications. For a consumer, it is easy to spot and distinguish Carbon Steel Pipe ASTM A 106 Gr C Pipes as it has a dull appearance similar to a matte finish. It looks like a cast iron pot and is not shiny. As for the composition, Carbon Steel Pipe ASTM A 106 Gr C Pipes is made of iron and carbon but it has more of carbon content and this higher carbon content gives it unique characteristics, which includes more malleability and durability. It also gets a lower melting point and better heat distribution. All these features make Carbon Steel Pipe ASTM A 106 Gr C Pipes highly useful for manufacturing pipes and tubes that are put to different uses like transmission, drilling, supply and the like.
Carbon Steel Seamless
Pipe PRODUCTS
Why purchase Carbon Steel Pipe ASTM A 106 Gr C Pipes from Rexal Tubes?
Rexal Tubes is an established name in the field of Carbon Steel Pipe ASTM A 106 Gr C Pipes and has been catering to the steel market for fifteen long years. The wide range of Carbon Steel Pipe ASTM A 106 Gr C Pipes supplied by the manufacturer has served customers with great efficacy not just in India but abroad as well. Businesses dealing in petroleum, water, oil & gas and other industries have been using the high-quality pipes and tubes of Rexal Tubes for a very long duration and they rely on the company with utmost faith. Their trust has earned the company a distinguished credibility which only gets fortified with its diverse and excellent supplies which serve regular, complex as well as emergency requirements of clients precisely.
Whether it is carbon steel ERW pipes or seamless pipes, Rexal Tubes offers the best in terms of quality and variety. The tubes and pipes are available in different sizes, shapes, thickness, diameter and other dimensions. There is also provision for after sale services. Most importantly, the Carbon Steel Pipe ASTM A 106 Gr C Pipes are flexible and open to being customized and so, a customer does not need to worry if they have a unique requirement. They can rest assured that they will be served the best Carbon Steel Pipe ASTM A 106 Gr C Pipes in every segment and the offering would prove to be value for money under all circumstances.
Carbon Steel Pipe ASTM A 106 Gr C pipes are used in the construction of petrochemical plants, power plants, oil and gas refineries, boilers and ships wherein fluids are transported.
Sizes (Seamless): 1/2″ NB – 60″ NB
Sizes (ERW): 1/2″ NB – 24″ NB
Sizes (SAW): 16″ NB – 100″ NB
Wall Thickness available:Schedule 20 – Schedule XXS (heavier on request) up to 250 mm thick.
SPECIFICATION | A106 NPS 1/8 — 48 ANSI Schedules to 160 | ||||||||||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
SCOPE | Covers SEAMLESS carbon steel nominal wall pipe for high-temperature service, suitable for bending, flanging and similar forming operations.NPS 1 1/2 and under may be either hot finished or cold drawn. NPS 2 and larger shall be hot finished unless otherwise specified. | ||||||||||||||||||||||||
KINDS OF STEEL PERMITTED FOR FOR PIPE MATERIAL |
Killed Steel Open-hearth Electric-furnace Basic-oxygen |
||||||||||||||||||||||||
HOT-DIPPED GALVANIZING |
Not covered in specification. | ||||||||||||||||||||||||
PERMISSIBLE VARIATIONS IN WALL THICKNESS |
The minimum wall thickness at any point shall not be more than 12.5% under the nominal wall thickness specified. | ||||||||||||||||||||||||
CHEMICAL REQUIREMENTS |
|
||||||||||||||||||||||||
TENSILE REQUIREMENTS |
Seamless Grade A Grade B Grade CTensile Strength, min., psi…………………….. 48,000 60,000 70,000 Yield Strength, min., psi………………………. 30,000 35,000 40,000 |
||||||||||||||||||||||||
HYDROSTATIC TESTING | Inspection test pressures produce a stress in the pipe wall equal to 60% or specified minimum yield strength (SMYS) at room temperature. Maximum Pressures are not to exceed 2500 psi for NPS 3 and under and 2800 psifor the larger sizes. Pressure is maintained for not less than 5 seconds. | ||||||||||||||||||||||||
PERMISSIBLE VARIATIONS IN WEIGHTS PER FOOT | Weight of any length shall not vary more than 10% over and 3.5% under that specified. NOTE — NPS 4 and smaller — weighed in lots. Larger sizes — by length |
||||||||||||||||||||||||
PERMISSIBLE VARIATIONS IN OUTSIDE DIAMETER | Outside Diameter at any point shall not vary from standard specified more than–
|
||||||||||||||||||||||||
MECHANICAL TESTS SPECIFIED | Tensile Test — NPS 8 and larger — either transverse or longitudinal acceptable Smaller than NPS 8 — weighed in lots. Larger sizes — by length. Flattening Test — NPS 2 and larger. Bending Test(Cold) — NPS 2 and under.
|
||||||||||||||||||||||||
NUMBER OF TESTS REQUIRED |
|
||||||||||||||||||||||||
LENGTHS | Lengths required shall be specified on order. No “jointers” permitted unless otherwise specified. If no definite lengths required, following practice applies: Single Random – 16′ – 22′. 5% may be 12′ – 16′ Double Random – Minimum length 22′, Minimum average 35′. 5% may be 16′ – 22′. |
||||||||||||||||||||||||
REQUIRED MARKINGS ON EACH LENGTH(ON TAGS ATTACHED TO EACH BUNDIE IN CASE OF BUNDLED PIPE) | Rolled Stamped or Stenciled (Mfgrs. option)
|
||||||||||||||||||||||||
GENERAL INFORMATION | Unless otherwise specified, pipe furnished with plain ends. Purchaser may specify NDE Surface finish standards are outlined in specification. in lieu of hydrostatic test or neither |
Hydrostatic Testing
The inspection test pressures create a stress in the wall of the pipe that goes to about 60% of the SYMS (specified minimum yield strength) at room temperature. 2500 psi for NPS3 and under 2800 psi for larger sizes are the maximum pressures that aren’t supposed to be exceeded. Pressure is maintained for 5 seconds or more.
Mechanical Tests Specified
Tensile Test — NPS 8 and larger — either transverse or longitudinal acceptable
Smaller than NPS 8 — weighed in lots. Larger sizes — by length.
Flattening Test — NPS 2-1/2 and larger.
Bending Test (Cold) — NPS 2 and under.
Degree of Bend | Diameter of Mandrel | |
For Normal A106 Uses | 90 | 12 x nom dia. of pipe |
For Close Coiling | 180 | 8 x nom dia. of pipe |
Carbon Steel Pipe ASTM A 106 Gr C Pipes Applications
Carbon Steel Pipe ASTM A 106 Gr C Pipes , as said above, is used in a number of industries and has a number of commercial applications in different industrial sectors. It can be used as structural piping equipment in construction or it can be used for transmission of oil, natural gas, petroleum, and water or as platforms on offshore rigs during drilling. It is a primary constituent in products like precision tubes, LPG cylinders, and others and it has a number of applications. It is suitable for welding, flanging, and other forming operations. Carbon Steel Pipe ASTM A 106 Gr C Pipes is notable for its flexibility and strength. This is the prime reason behind its growing popularity. It is fit for a broad range of services and therefore, it has been able to expand its scope of usage in different industries.
