EN 10083-2 GRADE C35 Pipe

EN 10083-2 Grade C35 Pipe

EN 10083-2 GRADE C35 Pipe

Over the past few decades, steel has emerged as one of the most reliable and useful materials for industries across the spectrum. It is used in different fields such as construction, manufacturing, and mining, and there is a huge demand for steel from all these industries to serve different mechanical purposes. Steel is used as a raw material to manufacture different products but there is one steel product that is used in different industries to execute different operations, which is a steel pipe. A much-relied and effective steel product, it is available in different forms and there are numerous variants of EN 10083-2 GRADE C35 Pipe that have made industrial operations smoother and more efficient.

EN 10083-2 GRADE C35 Pipe is one such variant that serves different piping requirements in different industries and has proven its worth through its substantial quality and ability to be used in multiple applications. For a consumer, it is easy to spot and distinguish EN 10083-2 GRADE C35 Pipe as it has a dull appearance similar to a matte finish. It looks like a cast iron pot and is not shiny. As for the composition, EN 10083-2 GRADE C35 Pipe is made of iron and carbon but it has more of carbon content and this higher carbon content gives it unique characteristics, which includes more malleability and durability. It also gets a lower melting point and better heat distribution. All these features make EN 10083-2 GRADE C35 Pipe highly useful for manufacturing pipes and tubes that are put to different uses like transmission, drilling, supply and the like. To get more details, Download EN 10083-2 GRADE C35 Pipe .

Carbon Steel Seamless
Pipe PRODUCTS

Low Temperature A-333 Grade Pipes

ASTM A 106 Grade Pipes

ASTM A106 Grade C Carbon Steel Seamless Pipes

RELATED PRODUCTS

Alloy Steel Pipes

Nickel Pipes and Tubes

ISO 3183 Pipe

Why purchase EN 10083-2 GRADE C35 Pipe from Rexal Tubes?

Rexal Tubes is an established name in the field of EN 10083-2 GRADE C35 Pipe and has been catering to the steel market for fifteen long years. The wide range of EN 10083-2 GRADE C35 Pipe supplied by the manufacturer has served customers with great efficacy not just in India but abroad as well. Businesses dealing in petroleum, water, oil & gas and other industries have been using the high-quality pipes and tubes of Rexal Tubes for a very long duration and they rely on the company with utmost faith. Their trust has earned the company a distinguished credibility which only gets fortified with its diverse and excellent supplies which serve regular, complex as well as emergency requirements of clients precisely.

Whether it is carbon steel ERW pipes or seamless pipes, Rexal Tubes offers the best in terms of quality and variety. The tubes and pipes are available in different sizes, shapes, thickness, diameter and other dimensions. There is also provision for after sale services. Most importantly, the EN 10083-2 GRADE C35 Pipe are flexible and open to being customized and so, a customer does not need to worry if they have a unique requirement. They can rest assured that they will be served the best EN 10083-2 GRADE C35 Pipe in every segment and the offering would prove to be value for money under all circumstances.

EN 10083-2 GRADE C35 Pipe Applications

EN 10083-2 GRADE C35 Pipe, as said above, is used in a number of industries and has a number of commercial applications in different industrial sectors. It can be used as structural piping equipment in construction or it can be used for transmission of oil, natural gas, petroleum, and water or as platforms on offshore rigs during drilling. It is a primary constituent in products like precision tubes, LPG cylinders, and others and it has a number of applications. It is suitable for welding, flanging, and other forming operations. EN 10083-2 GRADE C35 Pipe is notable for its flexibility and strength. This is the prime reason behind its growing popularity. It is fit for a broad range of services and therefore, it has been able to expand its scope of usage in different industries.

EN 10083-2 Grade C35 Specification

EN 10083-2 Grade C35 Carbon Steel Seamless Pipes and Tubes are also known as mild steel pipes and tubes. EN 10083-2 Grade C35 Pipes and Tubes are low-cost Low Carbon Steel Pipes and Tubes with max 020 % carbon content with combination of 050-140 % manganese easy to form and shape .These pipes are manufactured as per EN Specification and commercially referred as cs pipes or ms pipes.Low Carbon Steel Pipes are not as hard as high carbon steel pipes,Though carburizing can increase its surface hardness.

Chemical Properties

Carbon	Silicon	Manganese	Phosphorous	Sulphur	Molybdenum	Nickel	Chromium	Copper	Others
0.32-0.39	max 0.40	0.50-0.80	0.045	0.045	max 0.10	max 0.40	max 0.40	–	–

Mechanical Properties

Yield Strength		Tensile Strength			Elongation A5 min
MPa min	ksi min	MPa min	MPa min	ksi min	Percentage
		550	–	–	18

Equivalent Designation

DIN	EN	BS	NFA	ASTM	ASME
DIN 17204 Grade C35	EN 10083-2 Grade C35	NFA 49-311 Grade TU XC35	ASTM A519 Grade 1035	ASME SA 519 Grade 1035	–

Materials

Carbon Steel
Alloy Steel
Low Temperature Carbon Steel
High Temperature Carbon Steel
Low Temperature Alloy Steel
High Temperature Alloy Steel

Dimensional Tolerances of EN 10083-2 Grade C35

OD/Wall tolerance

OUTER DIAMETER AND WALL THICKNESS
Execution	Size Range	OD Tolerance	Wall tolerance
Hot-rolled Tube	OD – 80 mmOD > 80 mmWall	± 0.4 mm± 0.5 % of OD	± 0.7 mm± (5 % x wallthickness + 0.1 mm
Hot-rolled peeled tube	All sizesWall	+ 0.25/- 0 mm	± 0.8 mm± (5 % x wall thickness+ 0.2 mm)
Cold Worked tubecold-rolled or cold-drawn	OD 80 Wall Thickness 8	+ 0.30/- 0 mm+ 0.35/- 0 mm+ 0.40/- 0 mm*	± 0.30 mm± 0.35 mm± 0.40 mm

Straightness
The maximum deviation from the straight line is 1 mm on a gauge length of 1000 mm.

Ovality
The maximum out-of-roundness is 65% of the total outer diameter tolerance.

Standard length tolerances

Component length (mm)	OD 30-100 mm	OD 100-254 mm
10-100	+ 1.0/- 0	+ 2.0/- 0
100-600	+ 2.0/- 0	+ 3.0/- 0
600-1200	+ 3.0/- 0	+ 4.0/- 0
1200-5000	+ 5.0/- 0	+ 6.0/- 0

Dimensional Standards of EN 10083-2 Grade C35

FEDERAL

WWP-404c is similar to ASTM A-53 except that Government inspection and continuous identification marking of electric weld and seamless is mandatory. It covers black and galvanized welded and seamless pipe for flanging, bending, and coiling and for use with fresh water, oil, steam, air, and gas on shore plus a limited number of shipboard uses. Sizes 1/8 inch through 24 inch.WWP-406c is a federal specification comparable to ASTM A-120 (withdrawn 1988). Mills can certify that A-120 pipe in a distributor-s stock meets all the requirements of WWP-406c.

A.W.W.A.

C-200 covers black welded and seamless pipe intended for the conveyance of water in sizes 6 inch and larger. Specification prescribes hydrostatic test pressures for sizes of pipe covered. Tensile, flattening, and bending tests are required.

ASME

B31.1 Code for pressure piping.plants, and industrial plants.
B31.2 Fuel Gas Piping.
B31.3 Petroleum Refinery Piping.
B31.4 Liquid PetroleumTransportation Piping Systems.
B31.5 Refrigeration Piping.
B31.7 Nuclear Power Piping
B31.8 GasTransmission and Distributing Piping Systems. Covers design, fabrication, installation, inspection, testing, and the safety aspects of operation and maintenance of gas transmission and distribution systems.

ANSI (ASME)

B36.10 American Standard for Wrought-Steel and Wrought-Iron pipe. Designates dimensions, weights, and schedule numbers for welded and seamless pipe. Schedules 10 through Schedules Double Extra Heavy (DXH/XXH).
B36.19 American Standard for Stainless Steel Pipe. Designates dimensions, weights, and schedule numbers for welded and seamless Stainless Steel Pipe, Schedules 5 through Schedules 80.

A.A.R.

M-111 covers black and galvanized welded and seamless pipe intended for coiling, bending, flanging, and other special purposes and is suitable for welding. Purpose for which pipe is intended should be stated on orders. M-111 is comparable in most requirements to ASTM A-53.
M-130 covers black and galvanized welded and seamless pipe for ordinary uses in steam, water, gas, and air lines. Sizes 1/8 inch through 12 inch. Pipe to this specification is not intended for close coiling, bending, or high temperature service. M-130 is comparable in most requirements to ASTM A-120.
